18Gbps 4K HDMI2.0 over Optical Fiber Extender with Audio Extracting

18Gbps 4K HDMI2.0 over Optical Fiber Extender with Audio Extracting

Name: 18Gbps 4K HDMI2.0 over Optical Fiber Extender with Audio Extracting
SKU: LEDADVICES-CONVERTER-HDMI
Availability: InStock

Original price was: $800.00.Current price is: $600.00.

The HDMI 2.0 optical terminal can extend the HDMI signal to 10km (single-mode fiber) or 300 m (multimode fiber), with a maximum video resolution of 4K*2K@50 / 60Hz 4:4:4. It is widely used in exhibition and display, rail transit, radio and television, video conferencing, medical teaching, education recording, projection integration, and other high requirements for video industries.

Due to a few constraints, we are not able to showcase the pricing of some products, for more information kindly write us at sales@ledadvices.com or leave us messages on WhatsApp – Glad to hear from you!

Contact Now

Description

This HDMI Extender can extend HDMI signal up to 33000 feet/10 km (over single-mode fiber cable). It supports video resolution up to 4K2K@60Hz 4:4:4. Transmitter supports loop output, audio embedding and EDID management function. Receiver supports audio extracting function. In addition, the extender supports bidirectional IR control and RS-232 signal pass-through. It can allow you to easily control the display device on the signal source side or control the signal source device on the display side when using this extender.

It is widely used in exhibition and display, rail transit, radio and television, video conferencing, medical teaching, education recording, projection integration, and other high requirements for video industries.

Features:

HDMI 2.0b, HDCP 2.2 and DVI 1.0 compliant
Support 18Gbps video bandwidth
Video resolution up to 4K*2K@50/60Hz 4:4:4
HDMI audio formats: LPCM2/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
Support 3D and HDR format video, does not support CEC control
Transmission distance up to 33000 feet/10 km (over single-mode fiber cable)
* It is possible to use multi-mode fiber with these SFP modules but the distance can not be guaranteed.
Support bidirectional IR control, RS-232 pass-through and EDID management for simple and convenient control
Transmitter supports loop output (sharing local HD video and audio) and audio embedding function
Receiver supports audio extracting output function
Compact design for easy and flexible installation

Specification Download
